CPC General Catalog 2021

CPC - COLDER PRODUCTS COMPANY Smart fluid handling to take you forward, faster. WE INSPIRE CONFIDENCE AT EVERY POINT OF CONNECTION.

cpcworldwide.com · 1-800-444-2474

cpcworldwide.com · 1-800-444-2474 1 SMART FLUID® HANDLING TO TAKE YOU FORWARD, FASTER CPC (Colder Products Company) has been designing and manufacturing quick disconnect couplings, fittings and connectors since 1978. Our broad range of products are found in thousands of applications across many life sciences, specialty industrial and chemical handling markets. Used in a wide range of products, machinery, devices and processes, CPC’s innovative coupling and connection technologies allow flexible tubing to be quickly and safely connected and disconnected. The robust and easy-to-use design of CPC’s quick disconnect couplings and fittings provides reliable, secure and leak-free connections for fluid and air management. CPC makes people’s lives better by developing innovative high quality products that make fluid handling safe and easy. WHERE TO BUY Find your local distributor by visiting cpcworldwide.com or call CPC’s Customer Service at 1-800-444-2474 or 651-645-0091. You can also send an email to info@cpcworldwide.com. QUALITY CPC meets or exceeds our customers’ expectations. Everyone is involved, from our suppliers to our distribution network, and most importantly, our employees. CPC measures and continually improves our standards of product quality, support services and overall customer and employee satisfaction. CPC’s Quality System conforms to ISO 9001:2008 and ISO 13485 standards. Our cleanroom is ISO Class 7 certified.

cpcworldwide.com · 1-800-444-2474 TABLE OF CONTENTS 2 GENERAL PURPOSE PAGES 22-99 SMC & SMF1: Twist-to-connect design provides reliable and secure alternative to luer-type connections. MATERIAL: Acetal, polypropylene, ABS, chrome-plated brass TUBING ID SIZES: 1/16" to 1/8" (1.6mm to 3.2mm) PMC: Features one-hand connection and disconnection and wide range of tubing connection options; easier to use than ball-and-sleeve designs. MATERIAL: Acetal TUBING ID SIZES: 1/16" to 1/4" (1.6mm to 6.4mm) PMC12: Offered with a variety of configurations and chemical resistance for demanding applications; gamma sterilizable. MATERIAL: Polypropylene TUBING ID SIZES: Microbore to 1/4" (Microbore to 6.4mm) MC: Durable and able to withstand higher pressure and temperature; easy one-hand connection and disconnection. MATERIAL: Chrome-plated brass TUBING ID SIZES: 1/8" to 1/4" (3.2mm to 6.4mm) NS212: Twist-to-connect design features non-spill valves designed to provide fast, safe and leak-free fluid line connections. MATERIAL: Glass-filled polypropylene TUBING ID SIZES: 1/8" to 1/4" (3.2mm to 6.4mm) NS1: Smallest plastic non-spill coupling features enable secure connection and drip-free disconnect. MATERIAL: Glass-filled polypropylene, PEEK®, polypropylene TUBING: Microbore to 1/8" (Microbore to 3.2mm) PLC®: Widest selection of sizes and configurations offered; resistant to most mild chemical solutions. MATERIAL: Acetal TUBING ID SIZES: 1/4" to 3/8" (6.4mm to 9.5mm) DTLD: Unique thumb latch that enables independent connection and simultaneous disconnection of loose tube sets. MATERIAL: ABS TUBING ID SIZES: 1/4" to 3/8" (6.4mm to 9.5mm) 24 30 28 34 38 42 44 48

cpcworldwide.com · 1-800-444-2474 LEGEND NEW PRODUCT STRAIGHT-THROUGH SINGLE SHUT-OFF DOUBLE SHUT-OFF NON-SPILL RFID COMPATIBLE NSF LISTED OPTIONS AVAILABLE 3 PLC12: Materials of construction offer broad chemical resistance for demanding applications; gamma sterilizable. MATERIAL: Polypropylene TUBING ID SIZES: 1/4" to 3/8" (6.4mm to 9.5mm) LC: Durable and able to withstand higher pressure and temperature; easy one-hand connection and disconnection. MATERIAL: Chrome-plated brass TUBING ID SIZES: 1/4" to 3/8" (6.4mm to 9.5mm) APC: Features plastic thumb latch, fewer moving parts and a smooth contoured design to deliver ease-of-use and excellent flow. MATERIAL: Acetal TUBING ID SIZES: 1/4" to 3/8" (6.4mm to 9.5mm) DPC: Dual port connection in a contoured design that delivers ease-of-use and excellent flow in a compact size. MATERIAL: Acetal TUBING ID SIZES: 1/4" to 3/8" (6.4mm to 9.5mm) EFC12: High-efficiency valve design provides high flow capability; bulkhead panel mount option facilitates tight seals against tank walls and drums. MATERIAL: Polypropylene TUBING ID SIZES: 1/4" and 3/8" (6.4mm and 9.5mm) NS4: Non-spill coupling that virtually eliminates spills and minimizes downtime. MATERIAL: Glass-filled polypropylene, ABS TUBING ID SIZES: 1/8" to 3/8" (3.2mm to 9.5mm) 50 54 58 62 64 66

cpcworldwide.com · 1-800-444-2474 TABLE OF CONTENTS 4 EVERISTM PLQ2: Lightweight, reliable, non-spill liquid cooling coupling resistant to galvanic corrosion with a nominal flow of 1/8" (3.2 mm). MATERIAL: Polyphenylsulfone PPSU TUBING ID SIZES: 1/4" ID (6.4mm ID) EVERISTM PLQ4: Lightweight, non-spill liquid cooling coupling resistant to galvanic corrosion with a nominal flow of 1/4" (6.4 mm). MATERIAL: Polyphenylsulfone PPSU TUBING ID SIZES: 1/4" to 3/8" (6.4mm to 9.5mm) EVERISTM LQ8: Liquid cooling non-spill coupling for a secure, reliable connection and dripless disconnect with a nominal flow of 1/2" (12.7 mm). MATERIAL: Chrome-plated brass TUBING ID SIZES: 5/8" ID (15.9 mm ID) EVERISTM LQ6: Liquid cooling non-spill coupling for a secure, reliable connection and dripless disconnect with a nominal flow of 3/8" (9.5 mm). MATERIAL: Chrome-plated brass TUBING ID SIZES: 3/8" to 1/2" ID (9.5mm to 12.7mm ID) 76 78 74 72 EVERISTM LQ4: Liquid cooling non-spill coupling for a secure, reliable connection and dripless disconnect with a nominal flow of 1/4" (6.4mm). MATERIAL: Chrome-plated brass TUBING ID SIZES: 1/4" to 3/8" (6.4mm to 9.5mm) 70 EVERISTM LQ2: Liquid cooling non-spill coupling for a secure, reliable connection and dripless disconnect with a nominal flow of 1/8" (3.2 mm). MATERIAL: Chrome-plated brass TUBING ID SIZES: 1/4" ID (6.4mm ID) 68 GENERAL PURPOSE PAGES 22-99

cpcworldwide.com · 1-800-444-2474 LEGEND NEW PRODUCT STRAIGHT-THROUGH SINGLE SHUT-OFF DOUBLE SHUT-OFF NON-SPILL RFID COMPATIBLE NSF LISTED OPTIONS AVAILABLE 5 EVERISTM BLQ2: Ultra-reliable non-spill liquid cooling blind mate coupling for integrated mounting with a nominal flow of 1/8" (3.2 mm). MATERIAL: Chrome-plated brass TUBING ID SIZES: 1/4" SAE-4 80 EVERISTM BLQ6: Ultra-reliable non-spill liquid cooling blind mate coupling for integrated mounting with a nominal flow of 3/8" (9.5 mm). MATERIAL: Anodized aluminum TUBING ID SIZES: Insert: SAE-6, G 1/2 Body: SAE-6, G 1/2 84 EVERISTM BLQ4: Ultra-reliable non-spill liquid cooling blind mate coupling for integrated mounting with a nominal flow of 1/4" (6.4 mm). MATERIAL: Chrome-plated brass TUBING ID SIZES: Insert: G 1/4, G 3/8, SAE-4, SAE-6 Body: G 1/4, G 3/8, SAE-4, SAE-6, SAE-8 82 NSH: Pressure-balanced non-spill design with 100% metal-free, spring-free flow path. MATERIAL: Glass-filled polypropylene TUBING ID SIZES: 3/8" to 3/4" (9.5mm to 19.0mm) 88 NS6: Durable, yet lightweight construction that features non-spill valves and is compatible with many chemicals. MATERIAL: Glass-filled polypropylene TUBING ID SIZES: 3/8" and 1/2" (9.5mm and 12.7mm) 86

cpcworldwide.com · 1-800-444-2474 TABLE OF CONTENTS 6 106 102 104 MULTILINE PRODUCTS PAGES 100-109 HFC12: Efficient valve design leads to high flow and exceptionally low spillage; shrouded thumb latch is easy to grip and simple to operate. MATERIAL: Polypropylene TUBING ID SIZES: 3/8" to 3/4" (9.5mm to 19.0mm) HFC35 & 57: Withstand harsh environments and offered with or without UV-resistant materials to withstand harmful rays without affecting performance. MATERIAL: Polysulfone (white), UV-resistant polysulfone (black) TUBING ID SIZES: 3/8" to 3/4" (9.5mm to 19.0mm) FFC35: Features non-valved and unobstructed flow path to increase flow and minimize turbulence. MATERIAL: Polysulfone TUBING ID SIZES: 3/4" (19.0mm) 90 94 98 MULTI-MOUNT: Connects three to five lines at once; keyed to prevent mismatched connections. MATERIAL: Acetal, chrome-plated brass TUBING ID SIZES: 1/8" to 3/8" (3.2mm to 9.5mm) TENTUBE™: Allows connection and disconnection of up to ten lines with one slide latch; tubing orientation ensured by physical keying. MATERIAL: Nylon, acetal, polypropylene TUBING ID SIZES: 1/16" to 1/8" (1.6mm to 3.2mm) SIXTUBE™: Snap-in panel mount design and flexibility to connect and disconnect six separate lines with or without valves. MATERIAL: Acetal, polypropylene TUBING ID SIZES: 1/16" to 1/8" (1.6mm to 3.2mm) TWIN TUBE™: One easy-to-use quick disconnect for two separate non-valved flow paths. MATERIAL: Acetal, ABS TUBING ID SIZES: 1/16" to 1/8" (1.6mm to 3.2mm) GENERAL PURPOSE PAGES 22-99

cpcworldwide.com · 1-800-444-2474 LEGEND NEW PRODUCT STRAIGHT-THROUGH SINGLE SHUT-OFF DOUBLE SHUT-OFF NON-SPILL RFID COMPATIBLE NSF LISTED OPTIONS AVAILABLE 7 114 112 ENHANCED FUNCTIONALITY PAGES 110-119 116 MINI HYBRID CONNECTOR: A compact, single connection point combining 1 fluid line with 2 electrical lines with a breakaway mechanism for ease of use. MATERIAL: Glass-filled polypropylene HYBRID CONNECTOR: One integrated connector combining 2 fluid lines with non-spill couplings and 4 electrical lines to simplify the user interface. MATERIAL: Glass-filled polypropylene INTELLIGENT FLUID CONNECTIONS: Redefine what's possible for controlling, protecting and streamlining fluid handling with RFID-enabled couplings. MATERIAL: Acetal, polypropylene, glass-filled polypropylene

cpcworldwide.com · 1-800-444-2474 TABLE OF CONTENTS 8 MEDICAL GRADE PAGES 120-133 MPC™: Open-format connection for your 3/8" flow applications MATERIAL: Polycarbonate, polysulfone and silicone TERMINATIONS: 1/8", 1/4" & 3/8" (3.2mm, 6.4mm, 9.5mm); Sanitary: 3/4" & 1-1/2" BACK-TO-BACK ADAPTERS: Allow end users to connect single-use systems that may feature identical connections at the end of their tubing. MATERIAL: Medical-grade polycarbonate and polysulfone, USP Class VI SANITARY SERIES: Attaches directly to 3/4", 1" and 1-1/2" sanitary terminations to provide greater flexibility for integrating components into single-use or hybrid process systems. MATERIAL: Medical-grade polysulfone, USP Class VI, ADCF TERMINATIONS: 3/4", 1" and 1-1/2" sanitary 124 127 130 128 132 SMC: Twist-to-connect design manufactured and packaged in a cleanroom. MATERIAL: Medical-grade polycarbonate TUBING ID SIZES: 1/16" to 1/8" (1.6mm to 3.2mm) 122 MPX®: Open-format connection for your ½" flow applications MATERIAL: Polycarbonate, polysulfone, and silicone TERMINATIONS: 3/8", 1/2" (9.5mm & 12.7mm); Sanitary: 3/4" & 1-1/2" SANIQUIKTM: Integral sanitary termination attaches to hard-plumbed systems with tri-clover clamps; permits quick and easy connection to single-use bag systems, manifolds or tube sets. MATERIAL: 316L stainless steel TERMINATIONS: 3/4" and 1-1/2" sanitary

cpcworldwide.com · 1-800-444-2474 LEGEND NEW PRODUCT STRAIGHT-THROUGH SINGLE SHUT-OFF DOUBLE SHUT-OFF NON-SPILL RFID COMPATIBLE NSF LISTED OPTIONS AVAILABLE 9 HIGH PURITY PAGES 134-139 CHEMQUIK® DUAL CONTAINMENT SYSTEM: Flare nuts and panel mount fittings that facilitate double containment of critical chemical lines. MATERIAL: Natural, virgin polypropylene 139 CQG: Spring-free and metal-free flow path for high flow capacity and non-spill, high purity connections. MATERIAL: Natural, virgin polypropylene TUBING SIZES: 3/8" to 3/4" flare; 3/8" to 3/4" NPT 138 CQH: All plastic design for ultra-pure media and high chemical resistance. MATERIAL: Natural, virgin polypropylene and PVDF TUBING SIZES: 1/4" to 1/2" flare; 3/8" to 3/4" NPT 136

cpcworldwide.com · 1-800-444-2474 TABLE OF CONTENTS 10 DISPENSING PAGES 140-155 DRUMQUIK® ADAPTORS AND ACCESSORIES: CPC offers many accessories intended for use with DrumQuik® PRO and DrumQuik PUR systems. These include vent check valves, foot valves, fittings and more. 147 DRUMQUIK® PRO & DRUMQUIK PUR: Closed chemical dispensing system with a reusable coupler and a recyclable dip-tube assembly for chemical extraction from drums, jerry cans and IBCs. MATERIAL: Food grade, virgin polypropylene and polyethylene THREAD SIZES: Drum Inserts: 2" American buttress, BCS 56x4 and 2" NPS (G8), 70mm for BCS 70x5 and BCS70x6 Couplers: 1/2" NPT, 3/4" hose barb and 3/4" BSPP 144 142 BOTTLE ADAPTOR KITS: Intended for use on reagent bottles with SP400-38mm threads. MATERIAL: Natural, virgin polypropylene THREAD SIZES: SP400-38mm DRUMQUIK® ASIAN DRUM ADAPTORS, PLUGS AND CAPS DRUMQUIK® 3-PORT UDA: Used with 3/4" male NPT coupling terminations to adapt dip-tubes to standard drum closures for closed system dispensing. MATERIAL: Food grade, virgin polypropylene THREAD SIZES: UDA 3-Port: 3/4" male NPT; UDA: none 150 UDC: Provides closed connection to bag-in-box packaging with 38mm threaded and snap-in necks. MATERIAL: Polypropylene and acetal TUBING ID SIZES: 3/8" to 3/4" (9.5mm to 19.0mm) 152 PUNCTURE SEAL: Provides closed connection to Hedwin Cubitainer® bag-in-box container systems and flexible bags or bottles with SP400 38mm threads. MATERIAL: Polypropylene (coupling) and polyethylene (cap) TUBING ID SIZES: 1/4" and 3/8" (6.4mm and 9.5mm) 154 BQ45GL: Quick disconnect coupling or fitting integrated into a cap designed for 45GL bottles. MATERIAL: Polyethylene

cpcworldwide.com · 1-800-444-2474 LEGEND NEW PRODUCT STRAIGHT-THROUGH SINGLE SHUT-OFF DOUBLE SHUT-OFF NON-SPILL RFID COMPATIBLE NSF LISTED OPTIONS AVAILABLE 11 ACCESSORIES PAGES 164-169 FITQUIK® CONNECTORS: High-quality fittings for leak-free tubing connections. These precision-molded fittings are designed to reduce tubing leak points in applications such as medical devices, analytical instrumentation or air-driven equipment. 158 ACCESSORIES: Offering includes a variety of ancillary components from fittings and luers to PTF nuts and dust caps. 166 STERILIZATION AND DISINFECTANT METHODS 168 REGULATORY AND COMPLIANCE 169 FITQUIK® FITTINGS, LUERS, AND BLOOD PRESSURE CONNECTORS PAGES 156-163

cpcworldwide.com · 1-800-444-2474 12 OUR CAPABILITIES CPC’s engineered, custom solutions improve the overall functionality and design of the equipment and processes in which they are used. Special product features include precise hose barbs for superior grip, built-in shutoff valves to prevent product spills and an easy-touse, push-button thumb latch for quick disconnecting. CPC’s patented Hybrid Connector technology platform eliminates misconnections by integrating electrical, fluid and gas lines into a single connection point. RFID-enabled IdentiQuik® couplings redefine what’s possible for controlling, protecting and streamlining fluid handling processes. IdentiQuik technology allows the robust transfer of fluid and information to identify device type or connected media, verify line connection accuracy or capture fluid and product data. Specific applications for CPC connection technologies include: THERMAL MANAGEMENT CPC designs and manufactures Everis™ quick disconnect couplings (QDs) to specifically meet the demands for high performance in liquid cooling. Everis quick disconnect couplings from CPC are designed to optimize flow while offering excellent durability and ease of use; they are compatible with a variety of coolants. Most importantly, Everis quick disconnects’ patented non-spill design are ideal for long-term, connected use. Reliability is needed for sensitive and critical liquid cooling of electronics environments such as found in high performance computing, EV charging, data centers, 5G, and edge computing as well as medical electronics. LIFE SCIENCES CPC’s products are used across a broad range of medical devices and equipment, including surgical, dialysis, blood pressure monitoring, patient therapy devices, and in vitro diagnostics. A de facto standard in several applications, CPC connectors prevent misconnections and increase the ease of use of medical devices. Medical device OEMs around the world choose CPC connectors because of our proven performance in the operating room, the life science lab and the home healthcare setting. SPECIALTY INDUSTRIAL CPC’s couplings and fittings are installed in thousands of product applications. Our broad offering appeals to product manufacturers in a wide range of industrial and consumer-based markets, including analytical instrumentation, printing and ink management, engine systems, biohazard detection equipment, electronic cooling and portable hydration systems. CHEMICAL HANDLING CPC’s extensive options for chemically resistant quick disconnect fitments, closures, couplings and chemical dispensing systems provide non-spill operation chemical management environments. Applications include semiconductor, LCD, solar, pharmaceutical manufacturing and chemical management, pump, filter and de-ionized water connections, cleaning, soap and detergent dispensing, bulk ink management and consumer-based applications. Closed-loop dispensing systems enable fast, easy and economic chemical extraction from drums, IBCs and jerry cans.

cpcworldwide.com · 1-800-444-2474 13 ENGINEERED SOLUTIONS WORLDWIDE CPC innovates on the leading edge of what is possible and collaborates to develop the best solution for each customer. Many of CPC's standard couplings and fittings began as custom engineered solutions that found broader use in applicable markets. CPC delivers unmatched product design and quality with local engineering support in the United States, Europe and Asia. To date, CPC has produced over 12,500 custom and standard products to meet the fluid handling challenges of various industries worldwide.

cpcworldwide.com · 1-800-444-2474 14 HOW TO CHOOSE THE RIGHT CONNECTOR INTRODUCTION With so many connection options, it can often be an overwhelming task to decide which connector is best suited for an application. By understanding your application requirements and selecting the correct connection type, you will have better performance and sealing results. ASSESSING THE APPLICATION Understanding your application is the key to selecting the proper connection. Use the following guide to simplify your selection. Quality Quality is a key component of CPC’s success. We are ISO 9001:2008 and ISO 13485:2003 certified and our cleanroom is ISO Class 7 certified. Global Distribution Find your local distributor by visiting cpcworldwide.com/ Contact us or call CPC’s Customer Service at 1-800-444-2474 or 651-645-0091. FLOW What is your required flow and pressure drop? Be sure to allow for the effect of shutoff valves and tubing connections on your calculations. TUBING What size tubing, both inner and outer diameter, are you using? MEDIA The viscosity and corrosiveness of the fluid going through the connection need to be considered. Make sure the media is chemically compatible with ALL coupling materials - including the seals, o-rings and springs. Double-check media compatibility. TEMPERATURE Know your minimum and maximum temperature range. Standard temperature ranges are from -40° to 200° F (-40° to 93° C) depending on connection material. PRESSURE What is the maximum pressure your connection will need to withstand during operation? Quick disconnects rated to 250 psi (17 bar) will handle most low pressure applications. TUBING CONNECTIONS Type: Hose barb, compression fittings and push-to-connect are the most common termination styles. Size: You will need to know ID for hose barbs, OD for push-in-fittings and tube ID and OD for compression. SHUTOFF OPTIONS Do you need automatic shutoff valves? Shutoff options are single, double and non-spill. MOUNTING OPTIONS How is the connection going to be configured into your application? Common mounting options include pipe thread, panel mount, in-line or elbow. SPECIAL REQUIREMENTS Sterilization, NSF listed, USP Class VI approved materials, special packaging, color coding, keying, etc.

cpcworldwide.com · 1-800-444-2474 15 VISIT US ONLINE FOR INTERACTIVE WEB TOOLS ALSO ON THE WEB • PRODUCT SPECIFIER • CHEMICAL COMPATIBILITY • ASK OUR ENGINEERS • CAD MODELS • WATCH PRODUCT VIDEOS https://www.cpcworldwide.com/ Contact-Us/Find-a-Distributor SCAN FIND A DISTRIBUTOR CPCWORLDWIDE.COM/DRUMQUIK CPCWORLDWIDE.COM/FITQUIK CPCWORLDWIDE.COM/MEDICAL CPCWORLDWIDE.COM

cpcworldwide.com · 1-800-444-2474 16 ABS Economical, medical-grade thermoplastic that withstands gamma and e-beam sterilization. It is commonly used in medical devices. ABS is an amorphous material with good physical properties and good impact resistance. ACETAL Strong, lightweight and economical material used for a wide variety of chemical and mechanical components. Acetal offers high strength and rigidity over a broad temperature range, low wear, toughness and resistance to repeated use. POLYAMIDE (Nylon) Very resistant to wear and abrasion, good mechanical properties even at elevated temperatures, low permeability to gases and good chemical resistance. PEEK® (Polyetheretherketone) Highly temperature resistant, engineered thermoplastic with excellent chemical and fatigue resistance. It exhibits superior mechanical and electrical properties. POLYCARBONATE Resistant to some chemicals, withstands sterilization and is typically transparent. It is commonly used in medical devices and offers impact resistance, outstanding dimensional stability and good optical properties. POLYETHYLENE Low-cost, chemically resistant thermoplastic. It is opaque and has good impact resistance. POLYPROPYLENE Excellent general purpose resin that is highly resistant to chemical attack from solvents and chemicals in harsh environments. In general, polypropylene is resistant to environmental stress cracking and it can be exposed to challenging environments. POLYSULFONE Rigid material with excellent strength, good chemical resistance; withstands repeated sterilization and higher temperatures than other thermoplastics. Its high hydrolytic stability allows its use in medical applications requiring repeated high temperature autoclave and steam sterilization. PPS (Polyphenylene Sulfide) Broadest resistance to chemicals as an advanced engineering plastic. PPSU (Polyphenylsulfone) Polyphenylsulfone is heat and chemically-resistant with high thermal and hydrolitic stability. The material is inherently flame retardant and is UL94 VO-rated. PTFE Chemically resistant to all chemicals and solvents with the exception of some molten metals, molten sodium hydroxide, elemental fluorine and certain fluorinating agents. PTFE offers chemical resistance and stability at high temperature. PVDF Tough engineering thermoplastic with a balance of physical and chemical properties that qualifies it for high performance in a wide range of applications. It is mechanically strong and tough, has good ductility and has a broad, useful temperature range. MATERIAL OPTIONS The type of media flowing through a connection can affect the strength, surface appearance, color and performance of the connection. Here are some guidelines for the different types of material. THERMOPLASTICS FLUOROPOLYMERS

cpcworldwide.com · 1-800-444-2474 17 ALUMINUM Lightweight metal with an available hard anodized finish for durability. Aluminum is non-toxic, non-magnetic, non-sparking and is known for its high strength to weight ratio. NICKEL-CHROME PLATED BRASS Rugged metallic material with an attractive appearance, chromeplated brass is excellent for higher pressure and temperature. DIE-CAST ZINC Durable and lightweight (about 20% less than comparable brass) material that withstands high pressure and temperature. STAINLESS STEEL Offers excellent corrosion resistance and is often used for connector components such as valve springs. TPE Thermoplastic Elastomer (TPE) is a blend of additives and copolymers in a special formulation that forms extremely durable bonds to a substrate, while offering the traditional properties of soft-touch overmold. TPV Thermoplastic Vulcanizate (TPV) is an alloy of polypropylene thermoplastic and fully vulcanized EPDM rubber. TPV is typically resistant to water, acids and bases. BUNA-N The most common o-ring material is Buna-N due to its solvent, oil and water resistance. It has a temperature range of -40° to 250° F (-40° to 121° C). EPDM Ethylene-propylene-diene rubber is a chemically-resistant family of compounds. CPC uses high quality peroxide-cured EPDMs that provide exceptional resistance to chemicals when using a wide range of temperatures. FFKM (Chemraz®, Simriz®, Kalrez®) Broadest range of chemical resistance of any elastomeric material, combining the resilience and sealing force of an elastomer with chemical resistance approaching that of PTFE. FKM Well-known for its outstanding resistance to heat, oxidation, weathering and ozone. The temperature range is -15° to 400° F (-26° to 204° C). PFA & FEP ENCAPSULATED SEALS Encapsulated seals combine the resiliency of the elastomer with the superior chemical resistance of the fluoropolymer to achieve a seal that is lower cost than a pure fluoroelastomer FFKM seal. SILICONE Seals have good temperature resistance. The temperature range is -70°F to 400°F (-57°C to 204°C) with special compounds that can reach up to 450°F (232°C). Silicone can also be supplied with Class VI requirements for life sciences applications. O-RING SELECTION Selecting the correct o-ring is essential to your application. One o-ring can offer you better chemical resistance, another can offer better heat resistance, a third can offer cold flexibility. Here are some guidelines for the different types of o-rings. THERMOPLASTIC ELASTOMERS ALLOYS THE RIGHT NUMBER OF BARBS Many things work together to determine the quality of the connection between a hose barb and the tubing it connects. The sharpness of the barb, surface finish and the barb angle all contribute to the overall quality of the connection. Failing to optimize these technical aspects will result in a poor connection, regardless of the number of hose barbs used. CPC offers a variety of hose barb styles and connection options for tubing ranging from 1/16" to 1" ID.

cpcworldwide.com · 1-800-444-2474 18 CUSTOM PROJECT CAPABILITIES We pride ourselves on creating inventive solutions for design engineers’ unique challenges. We understand that every project has its own timing, budget and difficulties. Drawing upon our skills for innovation, we can find the right solution for you from our existing products or engineer a custom-made connector. Count on us to deliver the fluid handling expertise and experience essential for your special unique project requirements. INNOVATION AND EXPERTISE PUT TO WORK FOR YOU CPC believes innovation is a result of collaboration. Our engineers, working closely with your team, help solve challenging design or technical issues and help you get to market faster. Partner with a company that has over 40 years’ experience working with thousands of fluid management scenarios. Our highly knowledgeable experts help identify your challenges and optimize connector solutions for you to consider. Trust us to create reliable connections for your fluid management system and much more. Collaborating early in your design process empowers you to find the perfect connector for your needs and a partner for the long haul. WHEN TO CONSIDER A CUSTOM PROJECT • New design would add value to product making it easier to use and more reliable • The specification cannot be met by an existing standard CPC product • The project has unique requirements such as budget or scheduling challenges Our Custom Engineering team supports a wide range of customer needs—from simple and minor modifications to fully customized systems. We're ready to meet your project fluid handing requirements. Talk to a CPC distributor or click on the QR Code to view our video on the benefits of partnering with us for your custom solution. MINOR MODIFICATIONS SCAN Innovative Fluid Management Solutions: CPC Quick Disconnect Fittings Discover the benefits of integrating CPC’s fluid connectors, couplings and fittings. With engineer-toengineer collaboration, CPC works with clients in a wide range of industries early in their design process to create custom quick connect and disconnect fittings that are unique to their fluid management systems.

cpcworldwide.com · 1-800-444-2474 19 AESTHETICS Aesthetics often play a key role in the acceptance of a product and give an overall perception of quality. Even the smallest components may have an effect on the aesthetics of your design. Turn to our team of engineering experts to help you optimize your connection interface design to match the specific aesthetics of your products. APPLICATION USE CASES Color Customization Working with our Custom Engineering team, a wide range of customers have customized their fluid connectors and couplings by matching colors to their user interface panel, their equipment colors or even their company colors. Additionally, color coding helps avoid confusion between fluids when connecting, making it easy to identify the fluids lines. In one example, a maker of hydration solutions needed a connector that was leak free and matched the colors of their personal hydration system. Collaborating with the customer’s design engineers, we developed a blue connector with a yellow latch that complemented the product’s color scheme and provided the user with a simple, leak-free way to stay hydrated while outdoors. Visual Keying Visual keying helps prevent misconnections and is especially important where there are many similar connectors as part of the user interface. While primarily used to eliminate misconnections, visual keying may also be used to avoid damage to connectors or equipment caused by jamming the connector into the wrong socket. Collaborate with our custom engineers to add the color coding you require to help eliminate misconnections and increase ease-of-use for the user. Working together with an electronic equipment manufacturer, CPC Custom Engineering engineered a quick disconnect coupling that is color coded red or blue to help technicians identify which part of the system’s cooling loop is associated with the connector. Color coding helps indicate the temperature of the coolant in the specific area of the liquid cooling system. ENGINEERED SOLUTIONS

cpcworldwide.com · 1-800-444-2474 20 ENHANCED FUNCTIONALITY Fluid transfer connection technology expertise adds value to your products by: • Making your equipment, devices or instruments easier to use • Delivering enhanced reliability • Increasing design modularity • Enhancing serviceability • Providing an overall cleaner, faster and smarter connection If you can’t find the perfect solution from one of our thousands of standard products or you’d like to simply off-load the connector portion of your project to focus on your core technologies, CPC’s Custom Engineering provides the expertise and experience in fluid connection technology to assist you in finding the best options for your requirements. APPLICATION USE CASES Household Cleaning Product: floor mop A manufacturing company was looking to simplify the manufacturing assembly process of its floor mop with an attached cleaning fluid container. With multiple manual steps, including drilling a hole in the container cap, the manufacturing process was taking too much time to get the fluid connector onto the container. The manual steps were causing inconsistencies in assembly, increased number of products being rejected due to quality issues (especially fluid leakage) and added labor and material costs. Working with the manufacturer’s design team, our engineers developed a drop-in replacement that integrated a lightweight, chemically resistant coupling into the cap of the cleaning fluid container—eliminating the manual steps. The integrated coupling makes it easier to manufacture the mop and improves overall useability and serviceability. Most importantly, the integrated solution saves costs with fewer scrapped parts and less labor hours with shortened assembly times. COMPONENT INTEGRATION: PRINTER FILTRATION SYSTEM To make connections easier to use and provide a cleaner, more flexible design, many customers collaborate with CPC to develop connection solutions that incorporate functions beyond a standard fluid or air connection. Examples of these types of custom connections include integrating sensors, electrical lines, filtration components, and other types of functions. Our Custom Engineering team of materials scientists, design engineers and application engineers work side-by-side with your engineering team to get the right connector technology for your unique requirements. For instance, one large-format printer manufacturer needed to make changing the filter on its printers easier for its users and technicians while preventing ink from spilling when the filter was changed. Our Custom Engineering team, in conjunction with the manufacturer’s design team, developed a disk filter with an integrated, chemically compatible coupling that simplified the filter changing process. Matter of fact, with the coupling’s easy-to-use thumb latch for connection/disconnection, there are virtually no ink spills when the filter is changed.

cpcworldwide.com · 1-800-444-2474 21 ELECTRONIC INTEGRATION Equipment or devices with multiple connection interfaces are often confusing and time-consuming. Eliminate user confusion with one stress-free connection. Our team of engineering experts helps you optimize your primary user interface design with one integrated fluid and electrical connector specifically engineered to your performance requirements. If your design engineers need to specify, test and validate dozens of individual components to determine how to connect multiple lines to your devices, our custom-engineered connectors with electrical integration are the answer. Collaborating with our team to create a hybrid connector saves time and money with only one product to purchase and inventory— instead of a variety of individual components. APPLICATION USE CASES Aesthetic therapy devices: cosmetic laser devices for laser hair removal, photofacial skin rejuvenation, tattoo removal, etc. An aesthetician uses a handheld device with a liquid loop to cool the handheld, electrical lines for power and potentially video lines. CPC engineers, working with the manufacturers’ design team, developed a specific hybrid connector with integrated connections for these individual lines. The hybrid connector makes it easier for the user to change handhelds depending on the type of procedure and improves the overall design of the equipment. IVD instruments: flow cytometry equipment, routinely used in the diagnosis of health disorders especially blood cancers The flow cytometer uses large volumes of reagents and requires secure connections to ensure proper reagent delivery and waste collection. A custom engineered hybrid connector on the end of the cytometer’s umbilical line enables a single connection for monitoring fluid levels and transferring sheath or waste fluid. Containing a built-in level sensor and electrical connection, the hybrid connector alerts the cytometer when the buffer and rinse media are low and need to be replaced. CPC’s hybrid coupling provides quick and easy connection and disconnection to replace consumable fluids while at the same time reducing exposure to potential biohazardous spills on waste containers.

22 cpcworldwide.com · 1-800-444-2474

23 cpcworldwide.com · 1-800-444-2474 GENERAL PURPOSE Couplings and Connectors Optimize operational efficiency and productivity with a cleaner, faster and safer way to make a connection CPC general purpose connectors are versatile and engineered to fit a broad range of fluid handling applications. These multifunctional couplings offer a diverse set of options including terminations, configurations, sizes and materials. With decades of experience in delivering connection technology, CPC general purpose couplings and connectors have features that meet the precise needs of demanding users around the globe, including: • Precise hose barbs to improve the seal and grip for various grades of tubing • Thumb latch with an audible "CPC Click" for connection assurance • Non-spill technology to enhance equipment modularity Count on CPC general purpose connectors to get the job done. No matter what your application requires, every CPC coupling and connector is uniquely engineered to meet your needs.

24 cpcworldwide.com · 1-800-444-2474 SMC SERIES CONNECTOR The SMC and SMF1 are among CPC’s smallest couplings. These twist-to-connect couplings provide a reliable and more secure alternative to luer-type connections. They also allow for the tubing to rotate freely when connected. This important feature prevents both kinked tubing and accidental disconnection during use. DID YOU KNOW Polycarbonate SMC products manufactured in CPC's cleanroom are also available. FEATURES BENEFITS Twist to connect Prevents accidental disconnects Free coupling rotation Eliminates kinked tubing Quarter turn latch clicks when connected Prevents damage due to over torquing APC AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PLC AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) MC AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PRESSURE DROP, ∆ P (psi) EFC12 AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PMC AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) SIXTUBE AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PRESSURE DROP, ∆ P (psi) HFC12 AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) SMC AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) TENTUBE AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PRESSURE DROP, ∆ P (psi) HFC35/57 AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) r) i) FCC AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) r) i) BAC AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) r) i) i) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (bar) OW P, ∆ P (bar) PRESSURE DROP, ∆ P (bar) MC WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PMC WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) FPC WATER FLOW Flow (lpm) P, ∆ P (bar) P, ∆ P (psi) EFC12 WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) SMC WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) TEN TUBE WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) SIX TUBE WATER FLOW Flow (lpm) P, ∆ P (bar) P, ∆ P (psi) HFC WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) ZLC WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PLC12 WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PMC12 WATER FLOW Flow (lpm) P, ∆ P (bar) P, ∆ P (psi) HFC 35/57WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) These graphs are intended to give you a general idea of the performance capabilities of each product line. The shaded area of each graph represents the operating range of the product family, i.e., upper and lower values are shown. Therefore, depending on the exact coupling configurations selected, you can reasonably expect values to fall within the shaded area. cpcworldwide.com/SMC SCAN SPECIFICATIONS PRESSURE: Vacuum to 100 psi, 6.9 bar TEMPERATURE: Acetal, Chrome-Plated Brass: -40°F to 180°F (-40°C to 82°C) Polypropylene: 32°F to 180°F (0°C to 82°C) ABS: -40°F to 160°F (-40°C to 71°C) MATERIALS: Main Components: ABS, acetal, polypropylene, chrome-plated brass, stainless steel Locking sleeves: Acetal Valves: Acetal Valve spring: 316 stainless steel O-rings: Buna-N with acetal or chrome-plated brass, EPDM with polypropylene COLOR: Main components: Natural white (acetal and ABS), almond (polypropylene), chrome and black (acetal) TUBING SIZES: 1/16" to 1/8" ID, 1.6mm to 3.2mm and 5.0mm WARNING: Pressure, temperature, chemicals, and operating environment can affect the performance of couplings. It is the customer's r sponsibility to test the suitability of CPC products in their own application conditions. GENERAL PURPOSE

25 cpcworldwide.com · 1-800-444-2474 Q = Flow rate in gallons per minute CV = Average coefficient across various flow rates (see chart) P = Pressure drop across coupling (psi) S = Specific gravity of liquid SMM01 SMM02 SMF01 0.03 0.03 SMFD01 0.03 0.03 SMF02 0.03 0.19 SMFD02 0.03 0.08 SMPT02 0.03 0.19 SMFD02 0.03 0.08 INSERTS BODIES LIQUID FLOW RATE INFORMATION FOR COUPLINGS The chart below shows the flow rate for CPC couplings. Each coupling was tested with water at 70°F (21°C). To determine flow rates for specific coupling configurations use the formula below. CV VALUES

26 cpcworldwide.com · 1-800-444-2474 B A A B PANEL OPENING PANEL THICKNESS MAX. – MIN. PANEL NUT HEX PANEL NUT THREAD COUPLING BODIES 7/16 0.21 – 0.03 1/2 7/16-24UNF COUPLING INSERTS 7/16 0.21 – 0.03 1/2 7/16-24UNF PANEL DIMENSIONS C SMC SERIES DIMENSIONS COUPLING BODIES - Acetal COUPLING BODIES - Polypropylene SMF1 DISPOSABLE BODIES - ABS TERMINATION TUBING/THREAD SIZE METRIC EQ STRAIGHT THRU SHUTOFF A B C IN-LINE PIPE THREAD 1/8" NPT 1/8" NPT SMPT02 SMPT02BLK SMPTD02 SMPTD02BLK 0.51 (13) 0.51 (13) 0.86 (21.8) 0.86 (21.8) 7/16 (11.1) 7/16 (11.1) IN-LINE HOSE BARB 1/16" ID – – 1/8" ID 1/8" ID 1/8" ID 1.6mm ID 1.6mm ID 3.0mm ID 3.0mm ID 3.2mm ID 3.2mm ID SMF01 SMF01MBLK SMFM3 SMFM3MBLK SMF02 SMF02MBLK SMFD01 SMFD01MBLK SMFDM3 SMFDM3MBLK SMFD02 SMFD02MBLK 0.48 (12.2) 0.48 (12.2) 0.48 (12.2) 0.48 (12.2) 0.48 (12.2) 0.48 (12.2) 0.75/.90 (19.1/22.9) 0.75/.90 (19.1/22.9) 1 (25.4) 1 (25.4) 0.90 (22.9) 0.90 (22.9) PANEL MOUNT HOSE BARB 1/16" ID 1/16" ID – – 1/8" ID 1/8" ID 1.6mm ID 1.6mm ID 3.0mm ID 3.0mm ID 3.2mm ID 3.2mm ID SMFPM01 SMFPM01BLK SMFPMM3 SMFPMM3BLK SMFPM0212 SMFPM02BLK SMFPMD01 SMFPMD01BLK SMFPMDM3 SMFPMDM3BLK SMFPMD02 SMFPMD02BLK 0.58 (14.7) 0.58 (14.7) 0.58 (14.7) 0.58 (14.7) 0.58 (14.7) 0.58 (14.7) 0.75/.90 (19.1/22.9) 0.75/.90 (19.1/22.9) 1 (25.4) 1 (25.4) 0.90 (22.9) 0.90 (22.9) 1/2 (12.7) 1/2 (12.7) 1/2 (12.7) 1/2 (12.7) 1/2 (12.7) 1/2 (12.7) TERMINATION TUBING/THREAD SIZE STRAIGHT THRU SHUTOFF A B C IN-LINE PIPE THREAD 1/8" NPT SMPT0212 0.51 (13) 0.86 (21.84) 7/16 (11.1) IN-LINE HOSE BARB (ACETAL LOCKING SLEEVE) 1/16" ID 1/8" ID 1.6mm ID 3.2mm ID SMF0112 SMF0212 0.48 (12.2) 0.48 (12.2) 0.75/.90 (19.1/22.9) 0.90 (22.9) PANEL MOUNT HOSE BARB (ACETAL LOCKING SLEEVE) 1/16" ID 1/8" ID 1.6mm ID 3.2mm ID SMFPM0112 SMFPM0212 0.58 (14.7) 0.58 (14.7) 0.75/.90 (19.1/22.9) 0.90 (22.9) 1/2 (12.7) 1/2 (12.7) TERMINATION TUBING/THREAD SIZE STRAIGHT THRU SHUTOFF A B C IN-LINE HOSE BARB 1/8" ID 1/8" ID 3.2mm ID 3.2mm ID SMF10297 SMF10297MBLK 0.38 (9.7) 0.42 (10.7) 0.82 (20.8) 0.82 (20.8) PRODUCT DIMENSIONS A = Height/Diameter All measurements are in inches (millimeters) unless otherwise noted. Tubing must meet stated inside and outside diameters. MBLK = molded black material. BLK = dyed black material. B = Total Length C = Hex Size on Main Component

27 cpcworldwide.com · 1-800-444-2474 COUPLING INSERTS - Acetal COUPLING INSERTS - Polypropylene SMC COMPLETE IN-LINE COUPLINGS - Acetal SMC COMPLETE IN-LINE COUPLINGS - Polypropylene SMC ACCESSORY CHART - Acetal TERMINATION TUBING/THREAD SIZE METRIC EQ STRAIGHT THRU A B IN-LINE HOSE BARB 1/16" ID 1/16" ID – 1/8" ID 1/8" ID – – – 1.6mm ID 1.6mm ID 3.0mm ID 3.2mm ID 3.2mm ID 4.0mm ID 5.0mm ID 5.0mm ID SMM01 SMM01MBLK SMMM3 SMM02 SMM02MBLK SMMM4 SMMM5 SMMM5MBLK 0.48 (12.2) 0.48 (12.2) 0.48 (12.2) 0.48 (12.2) 0.48 (12.2) 0.48 (12.2) 0.48 (12.2) 0.48 (12.2) 0.75 (19.1) 0.75 (19.1) 0.8 (20.3) 0.8 (20.3) 0.9 (22.9) 0.9 (22.9) 1.02 (25.9) 1.02 (25.9) PANEL MOUNT HOSE BARB 1/16" ID 1/16" ID – 1/8" ID 1/8" ID 1.6mm ID 1.6mm ID 3.0mm ID 3.2mm ID 3.2mm ID SMMPM01 SMMPM01BLK SMMPMM3 SMMPM02 SMMPM02BLK 0.5 (12.7) 0.5 (12.7) 0.5 (12.7) 0.5 (12.7) 0.5 (12.7) 0.75 (19.1) 0.75 (19.1) 0.8 (20.3) 0.9 (22.9) 0.9 (22.9) TERMINATION TUBING/THREAD SIZE METRIC EQ STRAIGHT THRU A B IN-LINE HOSE BARB (ACETAL LOCKING SLEEVE) 1/16" ID 1/8" ID 1.6mm ID 3.2mm ID SMM0112 SMM0212 0.48 (12.19) 0.48 (12.19) 0.75 (19.1) 0.9 (22.9) PANEL MOUNT HOSE BARB (ACETAL LOCKING SLEEVE) 1/16" ID 1/8" ID 1.6mm ID 3.2mm ID SMMPM0112 SMMPM0212 0.5 (12.7) 0.5 (12.7) 0.75 (19.1) 0.9 (22.9) TERMINATION TUBING/THREAD SIZE METRIC EQ STRAIGHT THRU B IN-LINE HOSE BARB 1/16" ID 1/8" ID 1.6mm ID 3.2mm ID SMC0112 SMC0212 1.32 (33.5) 1.61 (40.9) TERMINATION O-RING MATERIAL PART NO. A B MALE PLUG Buna-N SMMP 0.48 (12.2) 0.50 (12.7) TERMINATION TUBING/THREAD SIZE METRIC EQ STRAIGHT THRU SHUTOFF B IN-LINE HOSE BARB 1/16" ID 1/16" ID – – 1/8" ID 1/8" ID 1.6mm ID 1.6mm ID 3.0mm ID 3.0mm ID 3.2mm ID 3.2mm ID SMC01 SMC01MBLK SMC02 SMC02MBLK SMCD01 SMCD01MBLK SMCDM3 SMCD02 1.32/1.46 (33.5/37.1) 1.32/1.46 (33.5/37.1) 1.62 (41.1) 1.62 (41.1) 1.61 (40.9) 1.61 (40.9) All measurements are in inches (millimeters) unless otherwise noted. Tubing must meet stated inside and outside diameters. MBLK = molded black material. BLK = dyed black material.

28 cpcworldwide.com · 1-800-444-2474 NS1 SERIES CONNECTOR NS1 Couplings compact design is packed full of features including non-spill shutoff valves that ensure drip-free disconnects, and eliminate the need to purge air from the system. The smallest plastic non-spill coupling on the market, NS1 is perfect for applications with tubing from 1/8-inch and smaller. Its rotating design allows tubing to move freely without kinks. Ideal for applications that need to be connected and disconnected often, the ergonomic, user-friendly interface enables a secure, reliable connect and disconnect. FEATURES BENEFITS Non-spill design Closed system for drip-free disconnect Ultra low air inclusion Minimizes contaminants, eliminates the need to purge air bubbles from the system Intuitive interface User friendly ergonomic design enables a secure, reliable connection Rotating design Allows tubing to move freely or relax without kinking or leaking Chemically resistant materials Reliable strength and performance in a range of applications cpcworldwide.com/NS1 SCAN PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (bar) W PRESSURE DROP, ∆ P (bar) SMC WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) TEN TUBE WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) SIX TUBE WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) MPX WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) NS1 WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) HFC WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) ZLC WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PLC12 WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PMC12 WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) HFC 35/57WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) SPECIFICATIONS PRESSURE: Vacuum to 15 psi, 1.0 bar TEMPERATURE: 32°F to 120°F (0°C to 49°C) MATERIALS: Main Components: Glass-filled polypropylene, PEEK®, polypropylene Thumb latch: PEEK® Springs: 316 stainless steel O-rings: EPDM COLOR: Gray TUBING SIZES: Microbore to 1/8" ID (Microbore to 3.2mm) SPILLAGE: 0.02 cc per disconnect rated @ 15 psi INCLUSION: 0.01 cc per connect WARNING: Pressure, temperature, chemicals, and operating environment can affect the performance of couplings. It is the customer's responsibility to test the suitability of CPC products in their own application conditions. This graph intended to give you a general idea of the performance capabilities of each product line. The shaded area of each graph represents the operating range of the product family, i.e., upper and lower values are shown. Therefore, depending on the exact coupling configurations selected, you can reasonably expect values to fall within the shaded area. GENERAL PURPOSE

29 cpcworldwide.com · 1-800-444-2474 PANEL DIMENSIONS PRODUCT DIMENSIONS A = Height/Diameter B = Total Length B A A B PANEL OPENING PANEL THICKNESS MAX. – MIN. PANEL NUT HEX PANEL NUT THREAD COUPLING INSERTS see drawing 0.29 – 0.05 5/8 1/2-24UNS Ø .500" +.010 -.000 .469" +.010 -.000 Greenlee® punch number 60077 TERMINATION TUBING/THREAD SIZE METRIC EQ. SHUTOFF A B IN-LINE HOSE BARB 1/8" ID 3.2 MM ID NS1D170212 0.61 (15.5) 1.33 (33.8) IN-LINE WITH A 1/4-28 FLAT BOTTOM PORT 1/8" OD OR SMALLER* 3.2 MM OD OR SMALLER* NS1D19042812 0.61 (15.5) 1.21 (30.7) IN-LINE WITH A 1/4-28 MALE THREAD NS1D10042812 0.61 (15.5) 1.28 (32.5) TERMINATION TUBING/THREAD SIZE METRIC EQ. SHUTOFF A B IN-LINE HOSE BARB 1/8" ID 3.2 MM ID NS1D220212 0.44 (11.2) 1.04 (26.4) IN-LINE WITH A 1/4-28 FLAT BOTTOM PORT 1/8" OD OR SMALLER* 3.2 MM OD OR SMALLER* NS1D26042812 0.44 (11.2) 0.92 (23.4) IN-LINE WITH A 1/4-28 MALE THREAD NS1D24042812 0.49 (12.4) 0.99 (25.1) PANEL MOUNT HOSE BARB 1/8" ID 3.2 MM ID NS1D420212 0.7 (17.8) 1.56 (39.6) PANEL MOUNT WITH A 1/4-28 FLAT BOTTOM PORT 1/8" OD OR SMALLER* 3.2 MM OD OR SMALLER* NS1D48042812 0.7 (17.8) 1.45 (36.8) COUPLING BODIES - Polypropylene COUPLING INSERTS - Polypropylene FERRULES ACCESSORIES FOR 1/4-28 NUTS AND FERRULES, SEE PAGE 37 OR VISIT CPCWORLDWIDE.COM DESCRIPTION MATERIAL PART NO. BULKHEAD O-RING: FOR SEALING PANEL MOUNT INSERTS LISTED ABOVE EPDM 731303 NS1 SERIES DIMENSIONS *Tubing size dependent on nut and ferrule used with 1/4-28 port.

30 cpcworldwide.com · 1-800-444-2474 PMC SERIES CONNECTOR The 1/8" flow PMC coupling covers a wide variety of general-purpose applications. Featuring the CPC thumb latch, the PMC is easier to use than ball-and-sleeve designs. One-hand connection/disconnection and integral terminations make the PMC the choice for ease of use and manufacture. This coupling is NuSeal® compatible. FEATURES BENEFITS Hose barb shroud Extra protection for the 1/16" hose barb Integral terminations Fewer leak points, shorter assemblies, faster installations Compatible Mates with PMC12 and MC Series couplings (see pages 34 and 38) Clicks when connected Assurance of a reliable connection cpcworldwide.com/PMC SCAN These graphs are intended to give you a general idea of the performance capabilities of each product line. The shaded area of each graph represents the operating range of the product family, i.e., upper and lower values are shown. Therefore, depending on the exact coupling configurations selected, you can reasonably expect values to fall within the shaded area. SPECIFICATIONS PRESSURE: Vacuum to 120 psi, 8.3 bar TEMPERATURE: -40°F to 180°F (-40°C to 82°C) MATERIALS: Main components and valves: Acetal Thumb latch: Stainless steel Valve spring: 316 stainless steel External springs and pin: Stainless steel O-rings: Buna-N COLOR: Natural white, others available TUBING SIZES: 1/16" to 1/4" ID, 1.6mm to 6.4mm ID WARNING: Pressure, temperature, chemicals, and operating environment can affect the performance of couplings. It is the customer's responsibility to test the suitability of CPC products in their own application conditions. APC AIR FLOW• 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PLC AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) MC AIR FLOW • 100 p ig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PRESSURE DROP, ∆ P (psi) EFC12 AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PMC AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) SIXTUBE AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PRESSURE DROP, ∆ P (psi) HFC12 AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) SMC AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) TENTUBE AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) Flow (scfm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PRESSURE DROP, ∆ P (psi) HFC35/57 AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) FCC AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) BAC AIR FLOW • 100 psig inlet pressure Flow (Nm 3 /min) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PRESSURE DROP, ∆ P (psi) e PRESSURE (bar) NS4 Pressure Range Temperature (°C) Temperature (°F) PRESSURE (bar) PRESSURE (psi) EFC12 Pressure Range Temperature (°C) Temperature (°F) PRESSURE (bar) PRESSURE (psi) PLC12 Pressure Range Temperature (°C) Temperature (°F) PRESSURE (bar) PRESSURE (psi) e PRESSURE (bar) HFC12 Pressure Range Temperature (°C) Temperature (°F) PRESSURE (bar) PRESSURE (psi) CQHD06 Pressure Range Temperature (°C) Temperature (°F) PRESSURE (bar) PRESSURE (psi) NS2 Pressure Range Temperature (°C) Temperature (°F) PRESSURE (bar) PRESSURE (psi) ge PRESSURE (bar) CQGD06 Pressure Range Temperature (°C) Temperature (°F) PRESSURE (bar) PRESSURE (psi) MPU Pressure Range Temperature (°C) Temperature (°F) PRESSURE (bar) PRESSURE (psi) PMC12 Pressure Range Temperature (°C) Temperature (°F) PRESSURE (bar) PRESSURE (psi) HFC35/37 Pressure Range Temperature (°C) Temperature (°F) PRESSURE (bar) PRESSURE (psi) PMC Pressure Range Temperature (°C) Temperature (°F) PRESSURE (bar) PRESSURE (psi) PLC Pressure Range Temperature (°C) Temperature (°F) PRESSURE (bar) PRESSURE (psi) NS6 Pressure Range Temperature (°C) PRESSURE (bar) PRESSURE (psi) e PRESSURE (bar) ge PRESSURE (bar) LC WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PLC WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) TWIN TUBEWATER FLOW Flow (lpm) RESSURE DROP, ∆ P (bar) RESSURE DROP, ∆ P (psi) APC WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) MC WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) MC WATE FLOW Flow lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) FPC WATER FLOW Flow (lpm) RESSURE DROP, ∆ P (bar) RESSURE DROP, ∆ P (psi) EFC12 WATER FLOW Flow (lpm) Flow (gpm) PRESSURE DROP, ∆ P (bar) PRESSURE DROP, ∆ P (psi) PRESSURE DROP, ∆ P (psi) PRESSURE DROP, ∆ P (psi) RESSURE DROP, ∆ P (psi) PRESSURE DROP, ∆ P (psi) GENERAL PURPOSE
